FBY-M series of six working positions hydraulic press machine
Model: FBY-

FBY-M series of six working positions hydraulic press machine
Non-standard plane can be customized according to customer''s demand
FBY-M10
Product Feature
1.The c-body design,compact stucture,overall casting make the machine high rigid.
2.The design of six station save time for clamping products and increase productivity.
3.Rod mechanical limit,under pressure stroke adjustable,positioning accuracy 0.02mm.
4.Safety designed,using both hands to operate,with emergency stop and jog up and down.
5.Key and foot switch two cycle start modes.
6.Widely used in parts of the press-fit shape,stretching,bending,punching,stamping,shaft alignment and press-fit etc.
7.Multi-station presses to reduce labor costs,reduce floor space,increase productivity,improve quality,increase efficiency.
8.Infrared protection can be configured(optional).
9.Failure warning,pre-diagnosis,failt diagnosis function(optional).

Technical Parameters
Theoretical output pressure 100(10T)Kn
Rated oil pressure 13Mpa
Max stroke 200mm
Max opening height 340mm
Throat depth 140mm
Fast-forward speed 110mm/s
Return speed 100mm/s
Feeding speed 10-100mm/s
Number working position 6
The size of the working table 680mm
The height of the working table 890mm
Power of motor 5.5Kw
Mold punting hole 32mm
Power 380V
Weight 1800kgs
